Settings for various network configurations
60
Table 2-6 Port numbers that must be registered as exceptions to a firewall between the
management client and storage subsystems
Port number Originator Destination Remarks
80/tcp
Management client
(web client)
• XP1024/XP128
• XP12000/XP10000/SVS20
0
• XP24000/XP20000
-
Legend
--: Not applicable
The following table describes the port numbers that must be registered as exceptions to a firewall
between the management server and a normal host.
Table 2-7 Port numbers that must be registered as exceptions to a firewall between the
management server and a normal host
Port number Originator Destination Remarks
2001/tcp
*
Normal host Management server -
24041/tcp
*
Management server Normal host -
24042/tcp
*
Management server Normal host -
Legend
--: Not applicable
*
This port number can be changed.
The following table describes the port numbers that must be registered as exceptions to a firewall
between the management server and a virtualization server.
Table 2-8 Port numbers that must be registered as exceptions to a firewall between the
management server and a virtualization server
Port number Originator Destination Remarks
5988/tcp
Management server vMA This setting is required for non-
SSL communication if the
configuration uses vMA.
5988/tcp
Management server VMware ESX This setting is required for non-
SSL communication if the
configuration does not use
vMA.
5989/tcp
Management server vMA This setting is required for SSL
communication if the
configuration uses vMA.
5989/tcp
Management server VMware ESX This setting is required for SSL
communication if the
configuration does not use
vMA.
