Settings for various network configurations
53
Table 2-2 Ports used by the Device Manager server
Port number Description
2001/tcp
*
Used for communication with management clients
(web client and CLI) and hosts (Device Manager
agents).
This port number is used as the temporary port
assigned by default in Windows. Therefore, HP
recommends that you change this port number setting
for the Device Manager server by modifying the
server.http.port property in the
server.properties file. Note that you cannot start
the Device Manager server if this port is being used
by another product.
After changing the port number, execute the
hdvmagt_account command to change the setting
for the Device Manager agent. For details about the
hdvmagt_account command, see the HP
StorageWorks XP Command View Advanced Edition
software Device Manager agent administrator guide.
2443/tcp Used for SSL communication with management
clients (web client and CLI).
This port number is used as the temporary port
assigned by default in Windows. Therefore, HP
recommends that you change this port number setting
for the Device Manager server by modifying the
server.https.port property in the
server.properties file.
IMPORTANT: You can also change Windows OS
settings by editing the registry. For details about how
to do this, see the Microsoft web site.
5983/tcp Used for receiving event indications from SMI-S
providers.You can change this port number by
modifying the
server.smisclient.indication.port property
in the server.properties file.
5988/tcp Used for non-SSL communication with the SMI-S
provider or CIM client.
You can change the port used for communication with
a CIM client by modifying the
server.cim.http.port property in the
server.properties file.
5989/tcp Used for SSL communication with the SMI-S provider
or CIM client.
You can change the port used for communication with
a CIM client by modifying the
server.cim.https.port property in the
server.properties file.
24220/tcp Used by HiRDB.
*
This port is also used when SSL is enabled. If you want to permit only SSL communication, set up a firewall
as described in section
2-1-3 .
