Settings for various network configurations
52
Table 2-1 Ports used by Common Component
Port number Description
23017/tcp Used internally for Common Component
communication (accessing HBase Storage Mgmt
Common Service through an AJP connection from
HBase Storage Mgmt Web Service).
If a product other than Common Component is using
this port number, change the settings of that product
or of Common Component. For details about how to
change the Common Component settings, see
section 2-1-2 .
23018/tcp Used internally for Common Component
communication (receiving a stop request from HBase
Storage Mgmt Common Service).
If a product other than Common Component is using
this port number, change the settings of that product
or of Common Component. For details about how to
change the Common Component settings, see
section
2-1-2 .
23032/tcp Used internally for Common Component
communication (HiRDB).
If a product other than Common Component is using
this port number, change the settings of that product
or of Common Component. For details about how to
change the Common Component settings, see
section
2-1-2 .
45001/tcp to 49000/tcp Used internally for Common Component
communication (HiRDB).
You cannot change the settings by using Device
Manager. If products using these ports are installed
on the same computer, change the settings of those
products.
*
This port is also used when SSL is enabled. If you want to permit only SSL communication, set up a firewall
as described in section
2-1-3 .
2-1-1-2 Ports used by Device Manager server
The following table describes the ports used by the Device Manager server.
Table 2-2 Ports used by the Device Manager server
Port number Description
162/udp Used for receiving SNMP traps from
XP24000/XP20000, XP12000/XP10000/SVS200,
XP1024/XP128, and XP512/XP48.
427/tcp Used for communication with a CIM client.
