Settings for various network configurations
51
2 Settings for various network
configurations
This chapter describes the settings required on a Device Manager server for various network
configurations.
• Port setting (section 2-1 )
• Settings required to use a management server that has multiple NICs (section 2-2 )
• Settings required to operate in an IPv6 environment (section 2-3 )
• Changing the IP address or host name of the management server (section 2-4 )
• Changing the URLs for accessing XP Command View AE Suite products (section 2-5 )
• Settings required when disconnecting the management server network (section 2-6 )
2-1 Port settings
This section describes the port numbers and firewall settings used by Device Manager.
2-1-1 Ports used by Device Manager
If you use Device Manager with other programs on a computer, be sure to avoid duplicating port
numbers.
2-1-1-1 Ports used by Common Component
The following table describes the ports used by Common Component.
Table 2-1 Ports used by Common Component
Port number Description
23015/tcp
1
Used for accessing the HBase Storage Mgmt Web
Service when communicating with management
clients (web client).
If a product other than Common Component is using
this port number, change the settings of that product
or of Common Component. For details about how to
change the Common Component settings, see
section
2-1-2 .
23016/tcp Used for accessing the HBase Storage Mgmt Web
Service when performing SSL communication with
management clients (web client).
If a product other than Common Component is using
this port number, change the settings of that product
or of Common Component. For details about how to
change the Common Component settings, see
section
2-1-2 .
