Overview
24
Table 1-8 Computer requirements (Linux)
Item Requirements
Prerequisite program
• gzip
2
• J2SE Java Runtime Environment 5.0.xx (xx is 03 or later)
3
• libstdc++33-32bit-3.3.3-7.8.1
4
NOTE: If adequate virtual memory is not allocated on the management server, the XP Command View AE
Suite products and any other installed programs might become unstable or might not start. To ensure stable
operation of the management server, in addition to the virtual memory required for the OS and other
programs, the management server also requires the amount of virtual memory required for both the products
shown in
Table 1-10 and Common Component.
In addition to the virtual memory required for all the products installed on a management server, be sure to
secure enough virtual memory (500MB) for Common Component.
Table 1-10 shows the virtual memory requirements for each product in version 6.4.
1
If the Device Manager server is used simultaneously with other software products, the physical memory
requirements of all of the software products must be taken into account.
2
This program is required for decompressing the installer.
3
The JRE is installed automatically when you install the Device Manager server.
4
This program is required if SUSE Linux Enterprise Server 10 SP3 (x64) is used for the management server
OS. Make sure that libstdc++33-32bit-3.3.3-7.8.1 is installed before you install the Device Manager
server.
Table 1-9 Virtual memory requirements for each product (Linux)
Product name Virtual memory requirement (MB)
Device Manager
*
1,024
XP Provisioning Manager (Included in Device Manager)
XP Tiered Storage Manager 600
NOTE: If you plan to install Device Manager and XP Tiered Storage Manager, and if 1,000 MB of virtual
memory is already used by the OS and other programs, you must secure more than 3,124 MB of virtual
memory.
1,024 (for Device Manager) + 600 (for XP Tiered Storage Manager) + 500 (for Common Component) + 1,000
(already used virtual memory) = 3,124
*
If the Device Manager agent is installed on the management server, you need to allocate additional virtual
memory for it. For details on virtual memory requirements and allocating virtual memory, see the description
of the server.agent.maxMemorySize property in the HP StorageWorks XP Command View Advanced
Edition software Device Manager agent administrator guide.
When you install the Device Manager server, directories require the disk space in the table below.
Note that the /opt/CVXPAE portion can be changed. Read it as the directory specified during
installation.
Table 1-10 Installation directories and required disk space (Linux)
Item Default installation directory Required disk
space
Installation directory for the Device
Manager server
/opt/CVXPAE
1.5 GB
Installation directory for the XP
Provisioning Manager server
/opt/CVXPAE/ProvisioningManager
