Appendix A Specifying properties
197
Default: 3:15
A-5-8 server.dispatcher.daemon.receiveTrap
This property determines whether to use the SNMP trap reception function.
To use the SNMP trap reception function, specify true. To not use the function, specify false.
The SNMP trap reception function uses port 162.
If port 162 is not used by another product when you perform a new installation of Device Manager,
this property is automatically set to true. If the port is used by another product, you need to change
the setting for that product or disable this setting in the window for setting up the SNMP trap
reception function, which is displayed during installation of Device Manager.
If this property is set to true, the SNMP trap information for storage subsystems will be output to
the log, regardless of the settings for the SNMP trap log output function. For details about how to
specify settings for the SNMP trap log output function, see section
A-9 .
Default: True
A-5-9
server.dispatcher.daemon.configUpdate.detection.interval
This property specifies the interval (in minutes) at which the Device Manager server checks whether
the configuration of XP24000/XP20000 is changed by a storage management tool other than Device
Manager (such as XP RAID Manager or SVP). If the Device Manager server detects changes in the
XP24000/XP20000 configuration, a warning message is displayed in Device Manager web client.
You can specify a value from 0 to 1440. If you specify 0, the Device Manager server does not check
whether the configuration of XP24000/XP20000 is changed.
Default: 10 (minutes)
CAUTION:
•
If a warning message is displayed in web client, manually refresh the corresponding storage subsystem
information.
You can also specify the settings so that information in the database is automatically updated in case a
user forgets to perform a manual refresh after changing the storage subsystem configuration. To do so,
set up the following properties:
○ server.dispatcher.daemon.autoSynchro.doRefresh property
○ server.dispatcher.daemon.autoSynchro.type property
• The Device Manager server cannot detect the following configuration change performed on
XP24000/XP20000:
○ Creating, changing, or deleting copy pairs
○ Changing the status of an LDEV (such as Normal, Blocked, or Copying)
○ Changing the access attribute of an LDEV (such as Read/Write, Read Only, or Protect)
• The Device Manager server treats the following operations as configuration changes of
XP24000/XP20000:
○ Restarting SVP
○ Refreshing the configuration information of XP24000/XP20000 displayed in XP Remote Web
Console.
○ Switching the SVP in a cluster configuration from the executing node to the standby node, or vice
versa.
○ Turning on the DKC
