Troubleshooting
177
Table 10-17 Details of requests and parameters output as XP Provisioning Manager server audit
log data
Request Description Output parameter
GetVolSumForModPool
Acquires summary information for
volumes to display the storage
pool change window.
• Names of the resource groups
in a storage pool from which
the volumes are acquired
• Resource identifier of the
storage subsystem to which
the acquired volumes belong
2
• Information about the
allocation plan
1
GetVolSumForUnAllocPool
Acquires summary information for
volumes to display a list of
unallocated LDEVs.
• Names of the resource groups
in a storage pool from which
the volumes are acquired
• Resource identifier of the
storage subsystem to which
the acquired volumes belong
2
• Information about the
allocation plan
1
IsUsedLogicVolName
Checks whether the logical
volume name is already in use.
• Resource identifier of the host
2
• Logical volume name
IsUsedVolGrpName
Checks whether the volume group
name is already in use.
• Resource identifier of the host
2
• Volume group name
ModAllocPl
Edits an existing allocation plan. Information about the allocation
plan
1
ModPool
Changes the storage pool that
owns the specified volume as
OWN.
• Resource group name to which
the volume belonged before
the move
• Resource group name after the
move
• Array of the resource
identifiers of the volume to be
moved
2
RefreshHostInfo
Refreshes host information. Resource identifier of the host to
be refreshed
2
ResumeOpr
Restarts the host setting operation
that has been suspended.
Operation ID acquired as the
return value of the host setting
operation API when the host
setting operation was suspended
SetLogLevel
Dynamically changes the log
output level.
Log output level
SetStatus
Changes the status (public or
private) of the provisioning plan.
• Resource identifier of the
provisioning plan
2
• Status after change (public or
private)
StartAddDevF
Creates a device file.
• Resource identifier of the
target host
2
• Resource identifier of the
target volume
2
• Type of the volume manager
to be used
• Volume group name
• Logical volume name
CAUTION: The volume group
name and logical volume name
are displayed only when they are
specified.
