Troubleshooting
173
Table 10-17 Details of requests and parameters output as XP Provisioning Manager server audit
log data
Request Description Output parameter
GetDevOprLogDtl
Acquires the details of the device
operation log information that has
the specified device operation log
ID.
Log ID
GetDevOprLogs
Acquires device operation log
information.
--
GetFiltSPoolDtl
Acquires storage pool information
for the specified resource group
and the resource groups
immediately below it.
• Target resource group name
• Information about the
allocation plan (if specified)
1
GetFiltSPoolSum
Acquires the storage pool
information for the specified
resource group
• Target resource group name
• Information about the
allocation plan (if specified)
1
GetFSys
Acquires the file system that has
the specified resource identifier.
Resource identifier of the file
system
2
GetFSysByHost
Acquires the file system of the
specified host.
Resource identifier of the host
2
GetFSysMP
Acquires, on the specified host,
the file system at the mount point.
• Resource identifier of the host
2
• Mount point
GetFSysSumHost
Acquires the file system of the
specified host.
Resource identifier of the host
2
GetHost
Acquires the host information that
has the specified resource
identifier.
Resource identifier of the host
2
GetHostByIPAddress
Acquires the host information that
has the specified IP address.
IP address
GetHostByName
Acquires the host information that
has the specified name.
Host name
GetHosts
If no parameters are specified:
Acquires information about all
managed hosts.
If a parameter is specified:
Acquires information about
hosts of the specified type.
If no parameters are specified:
None
If a parameter is specified:
Host type
GetHostSum
If no parameters are specified:
Acquires information about all
managed hosts.
If a parameter is specified:
Acquires information about
hosts of the specified type.
If no parameters are specified:
None
If a parameter is specified:
Host type
GetLicenseInfo
Acquires the license information. --
GetLogLevel
Dynamically acquires the log
output level.
--
GetOprEvent
Acquires a host setting event. Operation ID of the host setting
processing that was acquired as
the return value of the host setting
operation API
GetProvInfo
Acquires provisioning settings. Operation ID of the host setting
processing that was acquired as
the return value of the host setting
operation API
