Troubleshooting
161
Table 10-13 List of options in detail messages
Output character
string
Operation
smi-s
• If the target is ObjectName
Makes the name of the SMI-S Enabled subsystem the target.
• If the target is StorageArray
Makes only the SMI-S Enabled subsystem the target.
• If the target is URLLink
Makes only the URL of the management server for the SMI-S
Enabled subsystem the target.
split
Splits the pair.
suspend
Creates a 3DC pair by using XP Continuous Access Journal.
unassign
Disassociates a virtual volume from a pool.
validate:false
Does not validate HORCM files when modifying a pair.
validate:true
Validates HORCM files when modifying a pair.
waitingViewSynchro
Returns a completion response after the database is updated.
ZeroPageReclaim
Performs zero data discard to release unused space.
The table below shows the sequence in which attribute values are output for each element.
Table 10-14 Sequence in which attributes values are output for each element in a detail
message
Output
character string
Full name and content Sequence in which Attribute values are
output
1
alert number
Alert
Alert
(Information about the error
that occurred in Device
Manager or the storage
subsystem)
number
Alerts
Alerts
(A group of Alert elements)
--
<model name
2
- serial number - chassis number -
array group number>, number of chassis containing
the array group, array group number, array group
RAID level, CLPR number, emulation mode, optional
information for external array group, type
ArrGrp
ArrayGroup
(Information about the array
group of the storage
subsystem)
<model
2
- serialnum - chassis - number>, chassis,
number, raidType, clprNumber, emulation,
volumeType, type
<model name
2
- serial number>, <model name
2
-
serial number>
ArrRsrv
ArrayReservation
(Lock information of the
storage subsystem)
<model
2
- serialnum>, <model
2
- serialnum>
Value specified in ArrayValue
ArrV
ArrayValue(Element for
specifying a value if the
type of the parameter
specified in Param is array)
value
ChangedItem
ChangedItem
(Information about the data
changed in Device
Manager)
--
