Troubleshooting
158
Table 10-10 Information output in detail message parameters
Item Description
attributes
Format: info='...'
Attribute values specified for the element are output. When two or
more attribute values are output, they are separated by a comma
(,). Each attribute value is output as a character string or a numeric
value.
If no corresponding attribute was specified or nothing was specified
for the attribute value, no attribute value is output. If no attribute was
specified or nothing was specified for attribute values, this item is not
output.
If an attribute value contains a single-quotation mark (') or comma
(,), the quotation mark or comma is replaced with a question mark
(?).
For details on the sequence in which attribute values are output, see
Table 10-14.
The table below lists the commands that can be output in detail messages.
Table 10-11 Commands output in detail messages
Output
character
string
Full name Operation
Add
Add Addition
Del
Delete Deletion
Get
Get Acquisition
Ivk
Invoke General operation for an SMI-S
Enabled subsystem
Mod
Modify Modification
Set
Set Setting
The table below provides information on the targets that can be output in detail messages.
Table 10-12 Targets output in detail messages
Output
character
string
Full name Operation
Alerts
Alerts Alert information reference or deletion
ArrGrp
ArrayGroup Array group configuration change
ArrRsrv
ArrayReservation Subsystem reservation setting or information
acquisition
CFForRep
ConfigFileForReplication XP RAID Manager configuration file creation
COMEFSP
CreateOrModifyElementFro
mStoragePool
Volume creation in an SMI-S Enabled subsystem
ConfChange
ConfigurationChange Configuration change notification to the Device
Manager server
DataRetentio
ns
DataRetentions Data retention information setting or acquisition
DebugLevel
DebugLevel Debug level change or reference
ExpPaths
ExposePaths Paths set in an SMI-S Enabled subsystem
ExtArrGrp
ExternalArrayGroup External array group setting
Host
Host Host setting or reference
HostI
HostInfo Host (agent) configuration change or reference
HostModeOpt
HostModeOption Host mode option reference
