Troubleshooting
152
Example of message text output as audit log data when a user logs in:
"The login process has completed properly."
10-4-1-2 Message text output for Device Manager server processing
When the Device Manager server receives a request for Device Manager server processing (for
example, a request to change the configuration or to obtain information) or sends a response for the
request, message text about the request or response is output as audit log data. The following
explains the format of, and information in, the message text.
Format of message text when the Device Manager server receives a request to perform server
processing (if no error occurred):
unique-ID detail-message
Format of message text when the Device Manager server sends a response (if no error occurred):
unique-ID[ status] [ request-operation-start-unique-ID]
Format of message text when the Device Manager server receives a request to perform server
processing or sends a response (if an error occurred):
unique-ID error-message-ID
Table 10-4 Information in message text when the Device Manager server receives a request or
sends a response (for server processing)
Item Description
unique-ID
A unique request identifier. For response transmission, the unique ID of the
request is output. For processing via the SVP, this ID is also output as audit log
data on the SVP.
detail-message
Detailed information on the request. For details, see section
10-4-2 .
status
If the request and the operation are asynchronous, one of the following character
strings that indicate the result of polling is output:
• COMPLETED: The operation was successful.
• PROCESSING: Now operating
• FAILED: The operation failed.
request-
operation
start-unique-ID
A unique ID that indicates which response (the result of polling the server about
the requested operation) corresponds to which request, when a request and the
operation are performed asynchronously.
This ID corresponds to the message ID that is output as an attribute of the
RequestStatus element of GetRequestStatus (command: Get, target:
RequestStatus). This message ID is output to the detail message when a
request is received. For details on detail messages, see section
10-4-2 .
error message-
ID
The ID of the error message.
The following examples show output message text.
Example of message text output when the Device Manager server receives a request for server
processing (if no error occurred):
"123456789 AddLUN<SA info='D700-75010421'><Path info=',,0,4,15,0,'><LDEV
info='D700-75010421-31,,'/><LDEV info='D700-75010421-34,,'/></Path><Path
info=',,1,1,15,0,31'/><Path info=',,16,6,15,0,31'/><Path
info=',,0,4,15,1,35'/></SA>"
Example of message text output when the Device Manager server sends a response to a request
for server processing (if an error occurred):
"123456789 KAIC01014-E
"
