Troubleshooting
150
3. Execute the following command to start the HBase Storage Mgmt Common Service and the
Device Manager server:
installation-directory-for-Common-Component/bin/hcmdssrv -start
10-4 Checking audit log data
Audit log data has the following format.
• In Windows:
When you open an event by selecting Event Viewer and then Application, the following is
displayed in the Description area in Event Properties.
program-name [process-ID]: message-portion
• In Linux:
The contents of a syslog file
date-time server-name (or IP-address) program-name[process-ID]: message-portion
The format and contents of message-portion are described below.
NOTE: In message-portion, a maximum of 953 single-byte characters can be displayed in a
syslog file.
The output format of message-portion is as follows:
uniform-identifier,unified-specification-revision-number,
serial-number,message-ID,date-and-time,detected-entity,detected-location,audit-event-type,
audit-event-result,audit-event-result-subject-identification-information,
hardware-identification-information,location-information,location-identification-information,
FQDN,redundancy-identification-information,agent-information,request-source-host,
request-source-port-number,request-destination-host,request-destination-port-number,
batch-operation-identifier,log-data-type-information,application-identification-information,
reserved-area,message-text
Table 10-3 Information in message-portion
Item
*
Description
uniform-identifier
Fixed to CELFSS.
unified-specification-revision-
number
Fixed to 1.1.
serial-number
Serial number of audit log messages.
message-ID
Message ID.
For details, see section
6-2-1 .
date-and-time
The date and time when the message was output. This item
is output in the format of yyyy-mm-ddThh:mm:ss.stime-
zone.
detected-entity
Component or process name.
detected-location
Host name.
audit-event-type
Event type.
audit-event-result
Event result.
audit-event-result-subject-
identification-information
Account ID, process ID, or IP address corresponding to the
event.
hardware- identification-
information
Hardware model or serial number.
location-information
Identification information for the hardware component.
location-identification-information
Location identification information.
