Settings for CIM/WBEM (SMI-S CIMOM)
125
○ If the information of a command device defined in the perf_cmddev.properties file
matches the information of the command device recognized by the host, the following
message is displayed:
The definition of the command device is valid.
○ If the host does not recognize a command device defined in the
perf_cmddev.properties file:
The error message KAIC28615-W and information of the command device that is not
recognized by the host are displayed.
○ If a command device recognized by the host is not defined in the settings file:
The error message KAIC28616-W and information of the command device that is not
defined in the settings file are displayed.
Note that, if the settings for a command device are defined in the perf_cmddev.properties
file by using the format of version 6.3 or earlier, the command device is assumed to belong to
SLPR0.
write
This parameter outputs the settings of all command devices recognized by the host to the
perf_cmddev.properties file. If no command device recognized by the host is detected,
nothing is output to the perf_cmddev.properties file.
You can use the -file option to specify the desired file name. To specify the file name, you
can use an absolute or relative path.
If the specified file already exists, a message asking if you want to overwrite that file appears.
If you do not specify the -file option, the perf_cmddev.properties file will automatically
be overwritten.
7-8 User permissions for using CIM/WBEM
features
The following table lists the user permissions for using CIM/WBEM features, based on the Device
Manager permissions and executable CIM methods.
Table 7-6 User permissions for using CIM/WBEM features
Device Manager permissions Executable CIM methods
Resource
group
Admin Modify View Peer
*
Service
methods
(extrinsic
method)
CIM
operations
(intrinsic
method)
Yes Yes Yes -- Permitted Permitted
-- Yes Yes -- Permitted Permitted
-- -- Yes -- Not permitted Permitted
All Resources
-- -- -- Yes Not permitted Permitted
