Settings for CIM/WBEM (SMI-S CIMOM)
124
• In Windows:
installation-folder-for-the-Device-Manager-agent\bin\perf_findcmddev {
view | verify | write [-file file-name] }
• In Linux:
installation-directory-for-the-Device-Manager-
agent/bin/perf_findcmddev { view | verify | write [-file file-name] }
The parameters for the perf_findcmddev command are described below.
If you specify no parameter, multiple parameters, or upper-case parameters, the method for
specifying the command is displayed.
view
This parameter displays the settings for the command devices defined in the
perf_cmddev.properties file.
Table 7-5 describes the command device settings displayed
by the perf_findcmddev command.
Table 7-5 Command device settings displayed by the perf_findcmddev command
Item Description
Raid ID
Displays the RAID ID.
R600 for HP XP24000
R601 for HP XP20000
R500 for HP XP12000
R501 for HP XP10000
R502 for SVS200
Serial#
Displays the serial number of the storage subsystem by using a decimal (base 10)
number.
SLPR#
Displays the number of the SLPR to which the command device belongs by using a
decimal (base 10) number.
If no number is defined for the SLPR, a hyphen (-) is displayed.
LDEV#
Displays the CU:LDEV number of the command device by using a decimal (base 10)
number.
Device file
name
Displays the command device identifier (the physical drive number, VolumeGUID, or
device file name) recognized by the host.
If an unrecognizable value is defined in the perf_cmddev.properties file, that value is
displayed as UNKNOWN. On lines where the definition does not follow the proper format, all
information is displayed as UNKNOWN. Comment lines and blank lines are not displayed. In
addition, if no value is specified in the perf_cmddev.properties file, only the header is
displayed.
The following is an example of output from the command.
Raid ID Serial# SLPR# LDEV# Device file name
R500 14050 0 345 \\.\PhysicalDrive3
R601 44332 1 456 \\.\Volume{xxxxxxx-xxxx-xxx-xxxxxxxx}
R501 UNKNOWN - 1045 \\.\PhysicalDrive10
verify
This parameter compares the settings for the command devices defined in the file
perf_cmddev.properties to the settings for the command devices recognized by the host.
If the host recognizes multiple command devices, the execution result is output for each,
regardless of whether the checked settings are valid.
