Settings for CIM/WBEM (SMI-S CIMOM)
112
Figure 7-1 CIM components for Device Manager
From a CIM client, you can specify a namespace by using the follow procedure:
• Specify the SMI-S version.
Specify root/smis/smisxx (xx is an abbreviation for the version number).
For example, to specify version 1.4.0, enter root/smis/smis14.
The latest namespaces that complies with the specified SMI-S version is selected.
• Specify the condition current.
Enter root/smis/current.
The current namespace is selected.
• Specify interop.
SMI-S 1.3.0 or a later version supports the namespace interop. If interop is specified as
the namespace, the Server profile that stores the current management server information is
specified.
The namespace of each vendor is accessed via this Server profile to obtain information about
the Array profile and its subprofiles.
NOTE: If you need to specify the namespace dmxx (xx is an abbreviation for the version number)
that was supported by Device Manager 5.8 or earlier versions, contact maintenance personnel.
The following table describes the correspondence between the namespaces supported by Device
Manager and SMI-S versions.
Table 7-1 Correspondence between namespaces and SMI-S versions
Namespace SMI-S
smisxx current interop
smis10
-- -- 1.0.2
smis11
-- -- 1.1.0
smis12
-- -- 1.2.0
smis13
-- -- 1.3.0
smis14
current interop 1.4.0
Legend: --: N/A
