DescriptionAttribute
Indicates the pool type.
The value output depends on the poolFunction value.
When poolFunction is 3:
• -1: None
• 16: Snapshot pool
When poolFunction is 4:
• -1: None
• 0: Main journal group (M-JNL) of Continuous Access Journal Software
• 1: Remote journal group (R-JNL) of Continuous Access Journal Software
• 2: Initialized journal group of Continuous Access Journal Software
• 3: Journal group of Continuous Access Journal Software or Hitachi Universal
Replicator for Mainframe Software that has no journal volumes
• 4: Main journal group (M-JNL) of Continuous Access Journal Software and
also remote journal group (R-JNL) of Continuous Access Journal Software
• 8: Main journal group (M-JNL) of Hitachi Universal Replicator for Mainframe
Software
• 9: Remote journal group (R-JNL) of Hitachi Universal Replicator for Mainframe
Software
• 10: Initialized journal group of Hitachi Universal Replicator for Mainframe
Software
When poolFunction is 5:
• -1: None
• 32: THP/Smart pool
• 33: MF-THP pool
When poolFunction is 6:
• -1: None
• 48: Fast Snap pool
poolType
Status of the pool
Valid for P9500 and XP24000/XP20000.
• 0: Normal
• 1: PFUS
• 16: Blocked
• 17: Over threshold
• 18: Regressed
• 19: Warning
• 20: Shrinking
-1 is output if no information can be acquired.
status
Threshold1 of the pool (%)
The value output depends on the poolFunction value.
• When poolFunction is 3: Threshold1 of the Snapshot pool
• When poolFunction is 5: Threshold1 of the THP/Smart pool
• When poolFunction is 6: Threshold value of the Fast Snap pool
This information is invalid for other cases (-1 is output).
threshold
