ObjectLabel instance
The ObjectLabel instance is output when one of the following commands is executed:
• GetStorageArray (subtarget=ArrayGroup) , page 126
• GetStorageArray (subtarget=LDEV) , page 145
• GetStorageArray (subtarget=LogicalUnit) , page 150
• AddLabel, page 60
• ModifyLabel, page 189
Table 133 ObjectLabel instance attributes
DescriptionAttribute
Object ID of the label
targetID
Label name
label
PairedPool instance
The PairedPool instance is output when the GetStorageArray (subtarget=Pool) command
(see “GetStorageArray (subtarget=Pool) ” on page 165) is executed.
Table 134 PairedPool instance attributes
DescriptionAttribute
The MU number of the paired pool
muNumber
The serial number of the paired pool
pairedSerialNumber
The type of paired pool storage system
A valid value is output for this item only when the storage system that contains the
paired pool has been registered in Device Manager.
pairedArrayType
Pool ID of the paired pool
pairedPoolID
PairedPortController instance
The PairedPortController instance is output when the GetStorageArray
(subtarget=PortController) command (see “GetStorageArray (subtarget=PortController)
” on page 175) is executed.
Table 135 PairedPortController instance attributes
DescriptionAttribute
Object ID of the paired port controller
pairedObjectID
Name of the paired port controller
This item is output if it has been registered.
name
CLI Reference Guide 349
