DescriptionAttribute
The status of a THP/Smart pool volume.
One of the following values is output for P9500:
• 2 : The THP/Smart pool can shrink.
• 1 : The THP/Smart pool is shrinking.
• 0 : The THP/Smart pool cannot shrink (for example, the initial THP/Smart pool
volume).
• -1 : The volume is normal (includes the volumes that became normal volumes
after the THP/Smart pool finishes shrinking).
-1 is output for other storage systems.
thpPoolVolControl-
Flag
Currently, this information does not apply to storage systems (-1 is output).
managementAreaPool-
ID
External LDEV tier rank
This attribute is output only if the microcode version of P9500 is 70-04-00-00/00
or later and the THP/Smart pool volume is an external volume.
externalTierRank
MFReplicationInfo instance
The MFReplicationInfo instance is output when the GetStorageArray
(subtarget=MFReplicationInfo) command (see “GetStorageArray (subtarget=MFReplicationInfo)
” on page 155) is executed.
Table 132 MFReplicationInfo instance attributes
DescriptionAttribute
Object ID of MFReplicationInfoobjectID
Serial number of the storage system containing the P-VOL
pvolSerialNumber
Type of the storage system containing the P-VOL
If the storage system containing the P-VOL is not registered, Unknown is output.
pvolArrayType
Device number of the P-VOL
pvolDevNum
Device number of the P-VOL
For P9500 or XP24000/XP20000:
The value is output in the ww:xx:yy format, where ww is the logical DKC
number, xx is the CU number, and yy is the LDEV number.
For XP12000/XP10000/SVS200:
The value is output in the xx:yy format, where xx is the CU number and yy
is the LDEV number.
displayPvolDevNum
P-VOL object ID
pvolObjectID
ID of the pool containing the P-VOL
If the value of replicationFunction is UniversalReplicatorForMF, a
journal group ID is output.
-1 is output for other copy types.
pvolPoolID
CLI Reference Guide 347
