DescriptionAttribute
Display name of the LDEV
displayName
Emulation mode
This item is output for P9500, XP24000/XP20000, XP12000/XP10000/SVS200,
or XP1024/XP128 (example: OPEN-8).
emulation
Number of cylinders in the LDEV
For P9500, XP24000/XP20000, XP12000/XP10000/SVS200, or
XP1024/XP128:
• When a mainframe volume or intermediate volume is used: Number of cylinders
in the LDEV
• When an open volume is used: 0
cylinders
Indicates whether the LDEV is used on a LUSE volume:
• 0: Not a LUSE volume
• 1: LUSE volume
isComposite
LDEV size (in KB)
sizeInKB
Number of LBAs
lba
RAID type of the LDEV
The RAID type is output in the format RAIDx(yD[+zP]) or RAIDx(yD[+yD]).
• RAIDx: RAID level
• yD: Number of data drives
• zP: Number of parity drives
For example, RAID5(3D+1P) indicates a RAID5 configuration consisting of three
data drives and one parity drive.
raidType
Indicates whether the volume is internal or external:
• 0: Internal volume
• 1: External volume
substance
Option information of the external volume
For P9500, XP24000/XP20000 or XP12000/XP10000/SVS200, a 3-bit value
is converted to decimal and is output.
• Bit 0 (0x01): Whether or not the cache mode is enabled
• Bit 1 (0x02): Whether or not the I/O suppression mode is enabled
• Bit 2 (0x04): Whether or not the cache inflow control mode is enabled
For each of these bits, 1 means enabled and 0 means disabled. For example,
when the cache mode and the cache inflow control mode are enabled, 5 is
output as the value of the volumeType attribute.
-1 is output in other cases.
volumeType
Slot size (KB)
This item is used by Cache Residency Manager (DCR).
slotSizeInKB
Number of the chassis containing the LDEV
chassis
Number of the parity group containing the LDEV
arrayGroup
Output items336
