HP P9000 Command View Advanced Edition Suite Software 7.4.0-00 CLI Reference Guide (TB581-96326, December 2012)

DescriptionStatusParameter name
Device number of the LU
For P9500 and XP24000/XP20000:
Specify this parameter as a decimal number or colon-delim-
ited hexadecimal number in the format ww:xx:yy, where
ww is the LDKC number, xx is the CU number, and yy is the
LDEV number. ww is optional. If ww is omitted, LDKC is as-
sumed to be 0.
For XP12000/XP10000/SVS200 and XP1024/XP128:
Specify this parameter as a decimal number or colon-delim-
ited hexadecimal number in the format xx:yy, where xx is
the CU number, and yy is the LDEV number.
The execution results are output in decimal.
Either the devnum or devnums parameter must be specified. Do
not specify both parameters at the same time. If they are specified
at the same time, an error will occur.
Optional
devnum
Device number of the LU
For P9500 and XP24000/XP20000:
Specify this parameter as a decimal number or colon-delim-
ited hexadecimal number in the format ww:xx:yy, where
ww is the LDKC number, xx is the CU number, and yy is the
LDEV number. ww is optional. If ww is omitted, LDKC is as-
sumed to be 0.
For XP12000/XP10000/SVS200:
Specify this parameter as a decimal number or colon-delim-
ited hexadecimal number in the format xx:yy, where xx is
the CU number, and yy is the LDEV number.
Use a comma to delimit multiple values.
The execution results are output in decimal.
Either the devnum or devnums parameter must be specified. Do
not specify both parameters at the same time. If they are specified
at the same time, an error will occur.
When you delete multiple LUs at once, you can specify the LUs
whose emulation type is OPEN-V.
Optional
(P9500,
XP24000/XP20000,
and XP12000/
XP10000/SVS200)
devnums
Parameter values to obtain in advance
serialnum and model
Obtain these values from the execution result of the GetStorageArray command. In the execution
result, use the arrayType value or the displayArrayType value to specify the model para-
meter, and use the serialNumber value to specify the serialnum parameter.
devnum or devnums
Obtain this value from the execution result of the GetStorageArray (subtarget=Logic-
alUnit) command. Execute this command by specifying only the model and serialnum
parameters, and LogicalUnit for the subtarget parameter. In the execution result of this
command, the devNum value appears in An instance of LogicalUnit. Use this devNum
value to specify the devnum or devnums parameter.
Command reference102
