3 Starting Up and Shutting Down the HP XC System
This chapter addresses the following topics:
• “Understanding the Node States” (page 51)
• “Starting Up the HP XC System” (page 52)
• “Shutting Down the HP XC System” (page 54)
• “Shutting Down One or More Nodes” (page 55)
• “Determining a Node's Power Status” (page 55)
• “Locating a Given Node” (page 55)
• “Disabling and Enabling a Node” (page 56)
3.1 Understanding the Node States
The nodes of the HP XC system exist in various states, which are described in Table 3-1.
A node's state depends on several factors, including the following:
• Is the node powered on?
• Does the node need to be imaged?
The software on client nodes must be synchronized with a central collection of software for
the nodes, called the golden image, which resides on a node called the golden client. Imaging
replicates the software from the golden client onto the node using the rsync or
flamethrower utilities. The golden image and software distribution are discussed in
Chapter 11: Distributing Software Throughout the System (page 141).
• Did the node fail to image?
• Did the node fail to boot?
Table 3-1 Node States
DescriptionNode State
The node requires imaging and is powered off.
Turning on the node's power initiates the imaging process.
Raw_Off
The node requires imaging and is powered on.
The node must be powered off to prepare for imaging.
Raw_On
The node is powered on and should have entered BIOS self-test.
The node can be imaged or booted.
POST
The node is in the process of imaging.
After a successful imaging, the node is placed in the Boot_Ready state.
If the node does not successfully image, the node is placed in the Image_Fail
state.
Imaging
The imaging operation failed. The node is returned to the Raw_Off state.Image_Fail
The node is imaged, but currently powered off.
The node is ready to boot. When the node is powered on, it is placed in the POST
state.
Boot_Ready
The node is booting.
If the node is successfully booted, the node will be placed in the AVAILABLE state.
If the node does not successfully boot, the node is placed in the Boot_Fail state.
Booting
3.1 Understanding the Node States 51
