/hptc_cluster/root/home/ovp_n16_mmddyy.tests
Details of this verification have been recorded in:
/hptc_cluster/root/home/ovp_n16_mmddyyr1.log
20.3 Using the dgemm Utility to Analyze Performance
You can use the dgemm utility, in conjunction with other diagnostic utilities, to help detect nodes
that may not be performing at their peak performance.
When a processor is not performing at its peak efficiency, the dgemm utility displays a WARNING
message.
Be sure to run this command from a systemwide directory, such as /hptc_cluster, because
the dgemm utility's output files are written by the nodes. By default, the dgemm utility creates
two output files:
• yyyymmdd.log
• yyyymmdd.chk
The yyyymmdd designates the year, month, and day the file was created. If the
detailed-output-flag is set to .true., additional log files for each processor are created.
Note:
Running the dgemm utility subsequently on the same day and from the same directory overwrites
the previous .log and .chk files.
By default, the dgemm utility identifies nodes with an average performance less than 90 percent
of their peak. The number of processors per node is one, for the purpose of calculating the average
performance. You can override these default values by specifying the override values in an input
file named input in the systemwide directory from which the dgemm utility is invoked. The file
has the following form (for clarity, it is continued on two lines in this document):
n m l inner-iteration-value outer-iteration -value cpus-per-node
cut-off detailed-output-flag
The following table describes these parameters and indicates their default values.
DescriptionDefault ValueParameter
The size of the matrix.1000
n
The size of the matrix.1000
m
The size of the matrix.1000
l
The number of inner iterations (timed).6
inner-iteration-value
The number of outer iterations (instance).10
outer-iteration
-value
The number of processors per node; this parameter is used to
calculate performance.
1
cpus-per-node
The point at which nodes are flagged.90
cut-off
A flag indicating whether or not the additional log files, one for
each processor, are generated (.true)) or not (.false.).
.false.detailed-output-flag
Use the following procedure to confirm the efficiency of the nodes in the allocation:
1. Change to a systemwide directory:
# cd systemwide-directory
20.3 Using the dgemm Utility to Analyze Performance 239
