On HP XC systems whose head node is either an HP CP6000 system or an HP CP4000 system,
you can only obtain the sensor and System Event Log information remotely.
14.8.5.1 Setting the BMI/IPMI Password Using an External Connection to the Head Node
Management Port
Allow access to the head node's management port through the external IP address, and
synchronize the management port passwords as shown by the following procedure:
NOTE: Substitute the node name (for example, n144) for the headnode variable.
1. Use the text editor of your choice to add the following line to the /etc/hosts file:
external-ip-address cp-headnode
For information on the /etc/hosts file, see hosts(5).
2. Use the ipmitool to set the BMC password.
IMPORTANT:
The commands to set the management port password differ depending on whether the IPMI
password has been configured or not (that is, whether the password is null):
• If the IPMI password has been configured previously, enter the following command:
# pdsh -a -x "headnode" 'ipmitool -I lan -P "oldpassword" \
-H cp-$(nodename) user set password 1 newpassword'
• If the IPMI password has never been configured, enter the following command:
# pdsh -a -x "headnode" 'ipmitool -I lan -P "" \
-H cp-$(nodename) user set password 1 newpassword'
The default password setting is a null ("").
NOTE: Setting the password returns a message like the following:
Close Session command failed
You can ignore this message.
14.8.5.2 Internal Connection to the Head Node's Console Port
If the head node's console port is connected internally, use the ipmitool command as follows
to synchronize the console port password throughout the HP XC system:
# pdsh -a 'ipmitool -I lan -P "oldpassword" \
-H cp-$(nodename) user set password 1 newpassword'
14.8.6 Changing the Nagios Administrator Password
Use the Apache server htpassword command to change the Nagios administrator password
as follows:
# /opt/hptc/nagios/etc/htpasswd.users nagiosadmin
The nagiosadmin user name and password are Web authorizations and are not governed by
the /etc/password file.
If your system runs the Apache server on a backup node in case of failover, you need to propagate
the /opt/hptc/nagios/etc/htpasswd.users database to that backup node. For information
on propagating software, see Chapter 11 (page 141) .
14.8.7 Changing the LSF Administrator Password
Use the following procedure to change the LSF Administrator password:
