10.3 Downloading and Installing Patches
Follow this procedure to download and install HP XC patches from the ITRC website:
1. Create a temporary patch download directory on the head node. You can name this temporary
directory anything you want; this procedure creates a directory called /home/patches:
# mkdir /home/patches
IMPORTANT: Although HP has no restrictions about where you download patches, do not
choose a directory that is included in the golden image because you do not want to distribute
the actual RPM files to all client nodes.
The example uses /home directory because it is not included in the golden image.
If necessary, you can exclude specific files from the golden image if they are not appropriate
for distribution to all client nodes, such as the RPM files. For more information on excluding
files from the golden image, see “Exclusion Files” (page 150).
2. Go to the ITRC website, and register as an Americas/Asia Pacific or European customer if
you have not previously done so. The web address is:
http://www.itrc.hp.com/
When you supply information about yourself and your corporation, an ITRC user ID is
assigned to you, and you supply your own password. Remember this user ID and password
because you must use it whenever you want to download a patch from the website.
3. From the registration confirmation window, select the option to go directly to the ITRC
home page.
4. From the IT Resource Center home page, select patch/firmware database from the
maintenance and support (hp products) list.
5. From the patch / firmware database page, select Linux under find individual patches.
6. From the search for patches page, in step 1 of the search utility, select vendor and version,
select hpxc as the vendor.
Select the HP XC version that is appropriate for the cluster platform.
If you are installing patches for SVA, select hpsva as the vendor.
7. In step 2 of the search utility, How would you like to search?, select Browse Patch List.
8. In step 4 of the search utility, Results per page?, select all.
9. Click the search>>> button to begin the search.
10. Download all patches that are available for the cluster platform into the temporary directory
you created.
If you are unable to retrieve the files from this website, contact the HP XC Support team at
the following email address:
xc_support@hp.com
11. Follow the patch installation instructions in the README file.
12. Proceed to “Rebuild Kernel Dependent Modules” if a new kernel has been supplied in a
patch.
10.4 Rebuild Kernel Dependent Modules
If a new kernel is supplied in a patch, you must rebuild all kernel dependent modules. It is
outside the scope of this document to list kernel-dependent modules. Therefore, it is your
responsibility to read the information in the patch README files to determine if a new kernel is
being installed, and you must know which modules are kernel dependent.
Be aware that some patches, such as a kernel patch, might require you to reboot the head node.
