Service Description Specifies the Nagios service name.
Actively launched on service node? Indicates whether or not Nagios periodically runs this
service check at the specified normal check interval.
Max Check Attempts Indicates the number of times Nagios examines the service
before reporting a failure.
Normal check Indicates the frequency of the check interval.
Retry check interval Indicates the amount of time Nagios waits before retrying
after a failure.
Table 8-3 Default Settings for Monitored Nagios Services
Retry Check
Interval
Normal Check
Interval
Max. Check
Attempts
Actively Launched
on Service Node?Service DescriptionHost Type
0h 2m 0s60h 0m 0s3YesConfiguration
Monitor
Master
0h 1m 0s0h 5m 0s3YesIP Assignment -
DHCP
Master
0h 2m 0s0h 5m 0s3YesManagement
Settings Monitor
Master
0h 2m 0s0h 3m 0s3YesResource MonitorMaster
0h 2m 0s0h 5m 0s3YesSlurm MonitorMaster
0h 2m 0s0h 10m 0s3YesSwitchMaster
0h 1m 0s0h 5m 0s3YesApache HTTPS
Server
Hub
0h 1m 0s0h 5m 0s3YesHost MonitorHub
0h 1m 0s0h 5m 0s3YesNagios MonitorHub
0h 10m 0s1h 0m 0s3YesRoot key
synchronization
Hub
0h 2m 0s0h 0m 0s3YesSensor Collection
Monitor
Hub
0h 2m 0s0h 1m 0s3YesSupermon Metrics
Monitor
Hub
0h 1m 0s0h 5m 0s3YesSyslog Alert
Monitor
Hub
0h 20m 0s60h 0m 0s1NoconfigurationCommon
0h 20m 0s1h 0m 0s3NoEnvironmentCommon
0h 20m 0s1h 0m 0s3NoLoad AverageCommon
0h 20m 0s1h 0m 0s3NoNodeInfoCommon
0h 20m 0s0h 5m 0s3YesPING InterconnectCommon
0h 2m 0s0h 10m 0s3NoResource StatusCommon
0h 2m 0s0h 10m 0s3NoSlurm StatusCommon
0h 20m 0s1h 0m 0s3NoSyslog AlertsCommon
0h 20m 0s0h 5m 0s3NoSystem Event LogCommon
0h 20m 0s1h 0m 0s3NoSystem Free SpaceCommon
124 Monitoring the System with Nagios
