8 Monitoring the System with Nagios
The Nagios open source application has been customized and configured to monitor the HP XC
system and network health. This chapter introduces Nagios and discusses these modifications.
This chapter addresses the following topics:
• “Nagios Overview” (page 105)
• “Using the Nagios Web Interface” (page 107)
• “Adjusting the Nagios Configuration” (page 114)
• “Configuring Nagios on HP XC Systems” (page 120)
• “Using the Nan Notification Aggregator and Delimiter To Control Nagios Messages”
(page 127)
• “Nagios Report Generator Utility” (page 127)
• “Modifying Nagios To Effect Changes” (page 130)
For information on using Nagios to monitor the optional HP Modular Cooling System (MCS),
see Appendix C (page 307).
8.1 Nagios Overview
The HP XC System Software uses the Nagios open source application to gather and display
system statistics, such as processor load and disk usage. Nagios watches hosts and services and
alerts you when problems occur or are resolved. HP XC System Software integrates Nagios with
software packaged with the HP XC System Software including Supermon, SLURM, and LSF.
The design of the Nagios application incorporates the concept of a plug-in, that is, an independent
file that extends the Nagios application. This design allows the development of service checks,
which are use to examine system and network services.
Nagios, as provided with the HP XC System Software, is configured with system and network
service checks already in place for your system; they were automatically configured for each
node with the nagios nconfig script when the cluster_config utility was run.
The HP XC system automatically configures the Nagios environment based on the configuration
of the HP XC system. Autoconfiguration is based on the information in the HP XC configuration
and management database (CMDB). The configuration is updated as a result of changes to the
HP XC database.
Nagios obtains most of its data from the Supermon open source monitoring application, which
is integrated with the HP XC System Software.
The Nagios master can be configured for improved availability. When configured for improved
availability, the head node must have the management_server role but not the
management_hub role; the other node in the availability set must have the management_server
role and the management_hub role. By default, the head node acts as the Nagios master and
the other node in the availability set acts as a Nagios_monitor. If the head node fails, the
availability tool reconfigures the other node in the availability set to act as both the Nagios master
and a Nagios monitor.
You can find the complete documentation for Nagios on the Nagios web address:
www.nagios.org
Specific information on Nagios features are available on the following web address:
www.nagios.org/about/
Additional information on Nagios is commercially available. The following web address lists
documents that describe Nagios and its use for system and network administration:
http://www.nagios.org/propaganda/books/
8.1 Nagios Overview 105
