Features Summary
The following table highlights the rules for having a mixed HP-UX 11i v1/v2/v3 vPars
environment.
Table 3-7 Mixed HP-UX 11i v1/v2/v3 vPars Environment Feature Summary
vPars A.03.05 instancesvPars A.04.xx instancesvPars A.05.xx instancesFeature
A.03.05A.04.02 or laterA.05.03Minimum vPars Version
NoNoYesvPars Monitor Supports
Mixed HP-UX 11i v1/v2/v3
vPars Environment
Not SupportedSupportedSupportedDynamic CPU Migration
Not SupportedNot SupportedSupportedDynamic Memory
Migration
Not Applicable
(vPars A.03.05 not
supported on Integrity)
Supported
(Integrity only)
Supported
(Integrity only)
HT OFF
Not Applicable
(vPars A.03.05 not
supported on Integrity)
Not SupportedSupported
(Integrity only)
HT ON
Not SupportedSupportedSupportedCell Local Processor (CLP)
Not SupportedSupportedSupportedCell Local Memory (CLM)
Not SupportedNot SupportedSupported
vparcreate, vparremove
Not SupportedNot SupportedSupported
vparmodify on other
virtual partitions
Mixed HP-UX 11i v1/v2/v3 vPars Environments in vPars A.05.03 65
