NOTE: In certain situations when using vPars with SAS disks on HP Integrity platforms,
the vparstatus -v and setboot commands may show different boot disk paths in vPars
mode. This is normal, and is due to the disks being scanned in a different sequence at boot
time.
You may see different boot disk paths for SAS disks reported by the vparstatus -v and
setboot commands in vPars mode after booting into nPars mode and then booting back
into vPars mode. For example:
— A virtual partition is ignited from a SAS disk and booted in vPars mode, and the
vparstatus -v command shows the boot disk path as A.
— If the system is booted back to nPars mode, the boot path may change to B, which is
different from A due to a different scan order. This would also change the boot path to
B in the vPars database (/stand/vpdb).
— After booting back to vPars mode, vparstatus -v for this virtual partition shows B
as the boot path and setboot still shows A.
Both boot paths (A and B) refer to the same SAS disk path.
• vPars and Dynamic nPartition Operations Dynamic nPartitions operations cannot be
performed to an nPartition that is running Virtual Partitions. For more information on
dynamic nPartitions, see the HP-UX 11i v3 Dynamic nPartitions white paper at: http://
docs.hp.com/en/10907/dynamic_nPars_WP.pdf.
Ordering vPars
For the latest information on ordering vPars, see the HP-UX Virtual Partitions Release Notes and
the HP-UX Virtual Partitions Ordering and Configuration Guide.
NOTE: The free product known as VPARSBASE is obsolete and is no longer available or
supported.
