# vparboot -p winona2 -I ww.xx.yy.zz,/opt/ignite/boot/Rel_B.11.11/WINSTALL
You will see a message similar to the following:
<MON> winona2 loaded
b. Press Ctrl-A until you see the console of the target partition. The console will display
the Ignite-UX installation interface.
c. Enter the boot disk path, lan info, hostname, and IP of the target partition into the
Ignite-UX interface and install HP-UX, desired patches, the Quality Pack bundle, the
vPars bundle, and the desired vPars-related bundles. As a result of this process, the
virtual partition will automatically reboot.
TIP: If you get a garbled display, you can press Ctrl-L to refresh the display.
Your system should now be booted with all virtual partitions up.
Installing vPars with Ignite-UX on Integrity
NOTE:
LAN Cards are Used for Boot During Installation on Integrity Systems Unlike vPars on PA-RISC,
vPars on Integrity uses the lan card of the target virtual partition for lanboot. Check that your
LAN card is supported for boot on 11.23 Integrity systems. For more information, see the HP-UX
Virtual Partitions Ordering and Configuration Guide.
Also, the I/O card and diagnostic utilities, such as FCFUPDATE and IODIAG.efi, will not operate
in vPars mode; you must be in nPars mode. If you need to update firmware, it will be easier
if you do so before booting in vPars mode. For information on modes, see “Modes: Switching
between nPars and vPars Modes (Integrity Only)” (page 122).
1. Prepare the nPartition for Installation of HP-UX by setting the nPartition’s acpiconfig
setting to default (for install of HP-UX) and verifying the hardware path of the first virtual
partition.
Example:
a. acpiconfig
Shell> acpiconfig
Acpiconfig settings: default
If you must change the acpiconfig setting from windows to default, you must first
enter the acpiconfig default command, and then immediately enter reset to
reboot using the new setting.
b. hardware path
fs0: Acpi(000222F0,915)/Pci(0|0)/Scsi(Pun6,Lun0)/HD(Part1,SigF4250000)
2. From EFI, boot your system using the Ignite-UX server.
Example:
Shell> lanboot select
01 Acpi(000222F0,0)/Pci(1|0)/Mac(00306E0E5268)
Select Desired LAN: 1
Selected Acpi(000222F0,0)/Pci(1|0)/Mac(00306E0E5268)
Running LoadFile()
CLIENT MAC ADDR: 00 30 6e 0e 52 68
DHCP
...
