6
group dgVM and configuring the VxVM disk group vmdatadg on top of it are given later in this
document.
Similarly, in a Metrocluster SRDF environment, this disk group should be configured as an SRDF
device group. In a Metrocluster Continuous Access EVA environment, this disk group should be
configured as an EVA data replication (DR) group.
Tables 1 and 2, respectively, describe the VxVM disk group layouts on Node1 and Node2, and on
Node3 and Node4.
Table 1: VxVM layout on Node1 and Node2
VxVM DG Logical volumes Local/Shared Purpose
Vmpriosdg osvol Local Contains the OS image
Vmpriexedg oraclevol Local Contains the Oracle binaries
Vmdatadg datavol Shared Contains the Oracle database
Table 2: VxVM layout on Node3 and Node4
VxVM DG Logical volumes Local/Shared Purpose
Vmsecosdg osvol Local Contains the OS image
Vmsecexedg oraclevol Local Contains the Oracle binaries
Vmdatadg datavol Shared Contains the Oracle database
Figure 2 shows the storage layout of the VxVM disk groups configured for setting up the virtual
machine.
