I/O: Allocation Notes
When planning or performing I/O allocation, note the following:
• An LBA can be assigned to at most one virtual partition at any given time. When you are
planning your I/O to virtual partition assignments, note that only one virtual partition may
own any hardware at or below the LBA (Local Bus Adapter) level. In other words, hardware
at or below the LBA level must be in the same virtual partition.
Example Looking at the ioscan output of a rp7400/N4000, the two internal disk slots use
the same LBA:
0/0 ba Local PCI Bus Adapter (782)
0/0/2/0 ext_bus SCSI C875 Ultra Wide Single-Ended
0/0/2/1 ext_bus SCSI C875 Ultra Wide Single-Ended
Therefore, you cannot assign one of the internal disks to partition vpar1 and the other
internal disk to partition vpar2; these disks must reside in the same partition.
• Syntax Notes
CAUTION: Using vPars A.03.01 or earlier, LBAs must be explicitly specified (included
in the hardware path). Specifying only the SBA is not supported. If specifying only an SBA,
the commands will not assume that all LBAs under the SBA are to be assigned; the system
may actually panic.
Beginning with vPars A.03.02, you can specify only the SBA. The vPars commands will
assume the change applies to all LBAs under the specified SBA.
The exception are boot disks; boot disks are specified using the full hardware path.
NOTE: When assigning I/O, if you specify a path below the LBA level (for example, cell/
sba/lba/.../device, vPars automatically assign the LBA to the virtual partition. For
example, if you specify -a io:0/0/0/2/0.6.0 where 0/0/0 is the cell/sba/lba, the lba
of 0/0/0 is assigned to the virtual partition. Further, this LBA assignment implies that all
devices using 0/0/0 are assigned to the virtual partition.
The assignment rules of LBAs remain applicable: the LBA can only be owned by one virtual
partition. For example, once the LBA at 0/0/0 is assigned to one virtual partition, it cannot
be simultaneously assigned to any other virtual partition. Thus, if the device at
0/0/0/2/0.6.0 is assigned to a virtual partition, the LBA at 0/0/0 is assigned to that virtual
partition, so the device at 0/0/0/2/0.6.0 cannot be assigned to a different virtual partition.
LBA Example
The vparcreate command on a non-nPartitionable system looks like:
#vparcreate -p vpar1 -a cpu::1 -a cpu:::1 -a mem::1024 -a io:0.0 -a
io:0.0.2.0.6.0:BOOT
where the I/O assignment is specified using the LBA level (-a io:0.0) and the boot disk
is specified using the full hardware path (-a io:0.0.2.0.6.0).
For an nPartitionable system, the vparcreate command would look like:
# vparcreate -p vpar1 -a cpu::1 -a cpu:::1 -a mem::1024 -a io:0.0.0 \
-a io:0.0.0.2.0.6.0:BOOT
where the I/O assignment is specified using the LBA level (-a io:0.0.0.) and the boot
disk is specified using the full hardware path (-a io:0.0.0.2.0.6.0).
For information on using the LBA level on nPartitionable systems, also see “Planning,
Installing, and Using vPars with an nPartitionable Server” (page 49).
• SBA/LBA versus cell/SBA/LBA When viewing hardware paths, note the following:
I/O: Allocation Notes 249
