HP System Management Homepage Installation Guide, March 2008

ReleaseStatusPathBundleProduct
HP-UX 11i v1, v2, v3Recommended:
Certain HP SMH
plugins, such as
Property Pages found
on the Home page
require it.
/usr/lib/sw/wbem/HPUXBaseAux for
HP-UX 11i v1 and v2.
SwMgmtMin for
HP-UX 11i v3.
HP-UX Software
Distributor
HP-UX 11i v1, v2, v3Recommended:
Certain HP SMH
plugins, such as
Property Pages found
on the Home page
require it.
/opt/lanprovider/WBEMP-LAN-00
LAN Provider for
Ethernet LAN
interfaces
HP-UX 11i v2, v3Optional: Certain HP
SMH plugins, such as
Property Pages found
on the Home page
require it.
/opt/fcprovider/FCProvider
WBEM Provider for
FC HBAs
HP-UX 11i v2, v3Optional: Certain HP
SMH plugins, such as
Property Pages found
on the Home page
require it.
/opt/scsiprovider/SCSIProvider
WBEM Provider for
SCSI HBA
HP-UX 11i v1, v2, v3Optional: Certain HP
SMH plugins, such as
Partition Manager
require it.
/opt/java1.4
Java2 1.4 SDK for
HP-UX (T1456AA)
Java
HP-UX 11i v1, v2, v3Optional: Certain HP
SMH plugins require
it; e.g., DSAU.
/usr/dt/lib/,
/usr/dt/lib/hpux32/,
and
/usr/dt/lib/hpux64/
CDE
HP-UX CDE User
Interface
HP-UX 11i v1, v2, v3Optional: Certain HP
SMH plugins require
it; e.g., fsweb.
/opt/atok/X11,
/usr/bin/X11 ,
and /usr/lib/X11/
X11
HP-UX X Window
Software
If you do not have these applications on your system, you can use the following resources to
install them before or after you install HP SMH:
• If you installed or updated HP-UX 11i v3 (B.11.31) from the media, then the applications
were recommended to install. If you installed or updated HP-UX 11i v1 (B.11.11) or HP-UX
11i v2 (B.11.23) from the media, then the applications were default installed. See the HP-UX
Installation and Update Guide on the HP Technical Documentation web site at http://
docs.hp.com for instructions on how to install and update HP-UX, including recommended
and default-installed HP application bundles. See “Using the Applications media” (page 22).
• You can use swinstall to install or update the bundles (for example, hpuxwsApache and
hpuxwsTomcat) using the HP-UX 11i v1 (B.11.11), HP-UX 11i v2 (B.11.23), and HP-UX 11i
v3 (B.11.31) media. See “Using the Applications media” (page 22).
• You can go to the Software Depot Home at http://www.hp.com/go/softwaredepot to search
for and download the application bundles. You can then use swinstall to install the
applications. See “Using Software Depot” (page 22).
• You can also download the bundles to a depot on your network and use Ignite-UX and
Software Distributor to install them. This process is helpful if you are creating one image to
install on multiple systems. See the Ignite-UX Administration Guide and the Software Distributor
Administration Guide on the HP Technical Documentation web site at http://docs.hp.com.
Installing HP SMH and dependent applications 21
