Software Distributor (SD-UX) Administration Guide HP-UX 11i v1, 11i v2, and 11i v3 (762797-001, March 2014)

1. Highlight SD-DATABASE (i.e., the example software) by clicking on it with the left mouse
button.
2. Choose Actions→Mark for Install (or right-click to display the pop-up menu and select Mark
for Install).
The Marked? column is set to Yes for SD-DATABASE.
Table 32 Software Selection List
Software Selection Window Object List
The Software Selection Window object list is hierarchical: you can open each object in the list and show objects
contained inside. Objects in the list that contain other objects that can be opened, have an arrow (→) after the
name.
For example:
• To see the subproducts in the product SD-DATABASE, double click on it. The object list displays the subproducts.
To open a subproduct, double click on the name. (Or highlight the name and then select Actions→Open Item.)
• To close an object and return to the previous list, double click on the first item in the list (..(go up)) or
highlight the item and selecting Actions→Close Level.
Note that products are listed together, but subproducts and filesets may appear in the same list when you
open a product.
3. Choose Actions→Install. This displays the Install Preferences dialog (Figure 51: “Install
Preferences Dialog”,).
Step V: Specify Install Preferences
The Install Preferences dialog box gives you the following optional selections: Preview, Schedule,
and OK.You can also enter a Job Title.
Figure 51 Install Preferences Dialog
126 Remote Operations Overview
