Configuring SNAplus2 for Enterprise Extender

Configuring SNAplus2 for Enterprise Extender White Paper 21
HPR/IP verification
After HPR/IP is activated, issue the following three commands to verify
Enterprise Extender is running:
1. D TCPIP, TCPIP, NETSTAT, DEV
2. D NET, ID=XCAEE
3. D NET, ID=PUTO
65, E
1. D TCPIP, TCPIP, NETSTAT, DEV
D TCPIP, TCPIP, NETSTAT, DEV shows the status of Virtual IP Adapter (VIPA)
and IUTSAMEH (VTAM) devices used for Enterprise Extender.
D TCPIP, TCPIP, NETSTAT, DEV
DEVNAME: VIPA DEVTYPE: VIPA
DEVSTATUS: READY
LNKNAME: VLINK LNKTYPE: VIPA LNKSTATUS: READY
NETNUM: 0 QUESIZE: 0
DEVNAME: IUTSAMEH DEVTYPE: MPC
DEVSTATUS: READY
LNKNAME: EELINK LNKTYPE: MPC LNKSTATUS: READY
NETNUM: 0 QUESIZE: 0
You should verify that:
The Virtual IP Adapter and IUTSAMEH (VTAM) have the link status of “READY”.
2. D NET,ID=XCAEE,E
D NET, ID=XCAEE, E shows a display of XCAEE (XCA major node) used for
Enterprise Extender.
D NET, ID=XCAEE,E
IST097I DISPLAY ACCEPTED
IST075I NAME = XCAEE, TYPE = XCA MAJOR NODE 222
IST486I STATUS= ACTIV, DESIRED STATE= ACTIV
IST1679I MEDIUM = HPRIP
IST1685I TCP/IP JOB NAME = TCPIPD
IST1680I LOCAL IP ADDRESS 172.168.1.2 (VIPA1)
IST1656I VTAMTOPO = REPORT, NODE REPORTED - YES
IST170I LINES:
IST232I L0000000 ACTIV
IST232I L0000001 ACTIV
IST232I L0000002 ACTIV
IST314I END
You should verify that:
The status of the XCA Major Node is set to ACTIV and that the following has
been configured:
HPRIP Me
dium=HPRIP (as opposed to CSMACD, ATM, or RING).
TCPIPD This
is the TCP/IP job name.
172.168.1.2 This i
s the local VIPA.
