HP-UX Reference (11i v2 04/09) - 1 User Commands A-M (vol 1)

l
lifinit(1) lifinit(1)
NAME
lifinit - write LIF volume header on file
SYNOPSIS
lifinit [-vnnn ][-dnnn ][
-n string ][-snnn ][-lnnn ][-ennn ] file
DESCRIPTION
lifinit writes a LIF volume header on a volume or file.
Options
lifinit recognizes the following options and command-line arguments which can appear in any order:
-vnnn Sets volume size to nnn bytes. If nnn is not a multiple of 256, it is rounded down to the
next such multiple.
-dnnn Sets directory size to nnn file entries. If nnn is not an integer multiple of 8, it is
rounded up to next such multiple.
-n string Sets the volume name to be string. If the
-n option is not specified, the volume name is
set to the last component of the path name specified by file. A legal LIF volume name is
6 characters long and is limited to uppercase letters (A-Z), digits (0-9) and the under-
score character (_). The first character (if any) must be a letter. The utility automati-
cally performs translation to create legal LIF volume names. Therefore, all lowercase
letters are converted to uppercase, and all other characters except numeric and under-
score are replaced with a capital letter
X. If the volume name does not start with a
letter, the volume name is preceded by a capital letter X. The volume name is also
right-padded with spaces or truncated as needed to be six characters long. If -n is
used with no string , the default volume name is set to 6 spaces.
-snnn set the initial system load (ISL) start address to nnn in the volume label. This is useful
when building boot media for Series 700/800 systems.
-lnnn specifies the length in bytes of the ISL code in the LIF volume.
-ennn set the ISL entry point to nnn bytes from the beginning of the ISL. For example, speci-
fying -e3272 means that the ISL entry point is 3272 (decimal) bytes from the begin-
ning of the ISL object module.
-Knnn forces the directory start location to be the nearest multiple of nnn × 1024 bytes from
the beginning of the volume. This is necessary for booting Series 700/800 systems from
LIF media.
If file does not exist, a regular HP-UX disk file is created and initialized.
The default values for volume size are 256 kilobytes for regular files, and the actual capacity of the device
for device files.
The default directory size is a function of the volume size. A percentage of the volume size is allocated to
the volume directory as follows:
Volume Size Directory Size
< 2MB ~1.3%
> 2MB ~0.5%
Each directory entry occupies 32 bytes of storage. The actual directory space is subject to the rounding
rules stated above.
Do not mount the special file while using
lifinit.
RETURN VALUE
lifinit returns exit code 0 if the volume is initialized successfully. Otherwise it prints a diagnostic
message and returns nonzero.
EXAMPLES
Initialize file
x to be a LIF volume containing 500 000 bytes with 10 directory file entries:
lifinit -v500000 -d10 x
Initialize device /dev/rdsk/c0t6d0 as a LIF volume using default initialization conditions (device
must not be a mounted file system device):
Section 1−−500 Hewlett-Packard Company − 1 − HP-UX 11i Version 2: September 2004
