Online Diagnostics (EMS and STM) Administrator's Guide September 2012

Table 13 Startup Configuration File Target Entries (continued)
DescriptionValuesKeyword
Port number on the host
that is used for network connection
Target TCP Port
Name of the log file to which
TCP events are sent
Target USERLOG
E-mail address of the recipient
of the events
Target E-MAIL Address
An optional field, which is
presented as user data for each
event meeting this criterion
Any text stringCOMMENT: (Optional)
File Locations
Table 3-6 describes the files used in hardware monitoring.
Table 14 File Locations
DescriptionDirectories and Files
Monitor executable files./usr/sbin/stm/uut/bin/tools/monitor/monitor_name
Default Monitor Configuration File./var/stm/config/tools/monitor/Global.cfg
Monitor-Specific Configuration File./var/stm/config/tools/monitor/monitor_name.cfg
Monitor Client Configuration File.
Available only for hardware monitors
/var/stm/config/tools/monitor/<monitor_name>.clcfg
converted to Multiple-View
(predictive-enabled).
Monitor Startup Configuration File./var/stm/config/tools/monitor/<monitor_name>.sapcfg
PSM configuration file./var/stm/config/tools/monitor/<monitor_name>.psmcfg
Hardware Monitoring Request Manager
file.
/etc/opt/resmon/lbin/monconfig
Startup client file./etc/opt/resmon/lbin/startcfg_client
PSM set_fixed utility file./etc/opt/resmon/lbin/set_fixed
Monitor dictionary file./etc/opt/resmon/dictionary/<monitor_name>.dict
In the Table 3-6, monitor_name is the name of a particular monitor, such as armmon.
Configuring Hardware Monitoring
This section describes how to configure hardware monitoring using the Hardware Monitoring
Request Manager (monconfig) utility. This section adresses the following topics:
• “Running the Monitoring Request Manager ” (page 32)
• “Enabling Monitoring ” (page 32)
• “Listing Monitor Descriptions ” (page 33)
• “Viewing Current Monitoring Requests ” (page 33)
• “Adding a Monitoring Request ” (page 34)
• “Modifying a Monitoring Request ” (page 36)
• “Verifying Hardware Event Monitoring ” (page 36)
• “Checking Detailed Monitoring Status ” (page 36)
Configuring Hardware Monitoring 31
