HP Storage Provisioning Manager (SPM) User Guide (5992-5070, March 2010)

6. Select the appropriate Requirement Type using the list:
• Select Shall not when requiring volume services which do not contain the specified property.
• Select Required when requiring volume services which do contain the specified property.
• Select Not Recommended when seeking volume services in which a property is not desired
but is allowed.
• Select Recommended when seeking volume services in which a property is desired but not
required.
7. Establish the constraint value by clicking the Edit Value button.
The appropriate dialog box opens.
8. For a Tag constraint, the Tag Constraints dialog box opens and displays a list of all Namespaces
and Tags available. Click the radio button to select the appropriate tag, then click the OK button
to return to the Goal Properties window.
NOTE:
If no tags have been established during the catalog configuration, no options will appear
in the dialog box. Without a value, the constraint cannot be saved. See
“Establishing tags” on page 15 to create the tags.
9. For a RAID constraint. the RAID Constraint dialog box displays. From the list, select the desired
RAID level, then click the OK button to return to the Goal Properties window.
Managing storage catalog entities50
