Installing and Configuring HP-UX IPFilter
Kernel Tunable Parameters
Chapter 116
Limits of fr_statemax
The tunable fr_statemax indicates the number of state entries that can
be created and exist at the same time. The ipfstat -s command gives
general state table statistics. When the number of states created reaches
fr_statemax, HP-UX IPFilter attempts to free up state entries and
increments the maximum counter. If HP-UX IPFilter fails to free up
state entries, no more state entries are created. The maximum counter is
incremented each time a state entry cannot be created because the state
table is full. If the state table is full, the connection is let through, but no
state entry is created. This is true even if DCA mode is enabled.
Limits of fr_limitmax
The tunable fr_limitmax has been deprecated and is no longer used to
control the number of limit entries that can be created on the system.
ipl_buffer_sz
The tunable ipl_buffer_sz can be used to modify the size of the HP-UX
IPFilter logging buffer for /dev/ipl.
The ipfstat –B command gives the size of the log buffer and buffer
space currently used. It also displays the log buffer high water mark,
which specifies the maximum value attained by the log buffer.
NOTE The ability to check the log buffer size and space used was previously
done using the ndd tunable cur_iplbuf_sz. This functionality has been
replaced by the ipfstat -B command.
For information on changing the ipl_buffer_sz variable, see
“Configuring Kernel Tunable Parameters” on page 17.
Tunable
Name
Default
Value
Minimum
Value
Maximum
Value
ipl_buffer_sz 8192 bytes 1024 bytes 163840 bytes
