Installing and Configuring HP-UX IPFilter
Step 2: Loading HP-UX IPFilter Software
Chapter 16
10. Click
Yes on the Confirmation window to confirm that you want to
install the software. The Install window opens.
View the Install window to read processing data while the software
is being installed. The Status field indicates Ready and the Note
window opens. The fileset is loaded by swinstall.
The estimated time for processing is three to five minutes.
11. Click
OK on the Note window once the install is complete.
12. After HP-UX IPFilter is installed, check the log files in
/var/adm/sw/swinstall.log and /var/adm/sw/swagent.log to be
sure the installation was successful.
13. Enable HP-UX IPFilter using the following command:
/opt/ipf/bin/ipfilter -e
NOTE Do not run the HP-UX IPFilter product when the system is booted in
single-user mode.
NOTE The IPFilter modules are dynamically linked into the kernel by
default. To statically link the modules, see Appendix B, “HP-UX
IPFilter Static Linking,” on page 175 for instructions and
information.
14. Go to Step 3: Determining the Rules for IPFilter.
