HP-UX IPFilter Utilities
The ipfstat Utility
Chapter 6 95
Displays detailed global limit statistics.
-r
<group:rule>
Displays the limit statistic by rule number.
-B
Displays the size of the log buffer and buffer space currently used.
-v
Sets verbose mode. Use for debugging.
NOTE Statistics counters cannot increment when both active in and out rule
sets are empty. This is due to a performance optimization that bypasses
IPFilter when there are no active rule sets present.
For a complete list of options used with ipfstat, see the ipfstat
manpage.
Examples
# ipfstat
dropped packets: in 0 out 0
non-data packets: in 0 out 0
no-data packets: in 0 out 0
non-ip packets: in 0 out 0
bad packets: in 0 out 0
copied messages: in 0 out 0
input packets: blocked 15 passed 2647 nomatch 2537 counted 0
short 0
output packets: blocked 0 passed 245 nomatch 141 counted 0
short 0
input packets logged: blocked 0 passed 0
output packets logged: blocked 0 passed 0
packets logged: input 0 output 0
TCP connections: in 5 out 50
log failures: input 0 output 0
fragment state(in): kept 0 lost 0
fragment state(out): kept 0 lost 0
packet state(in): kept 5 lost 0
packet state(out): kept 0 lost 0
ICMP replies: 0 TCP RSTs sent: 0
Invalid source(in): 0
