HP-UX AAA Server A.08.01 administrator's guide (T1428-90072, May 2010)

NOTE: In the above example, few entries have wild card “*” code configured which
would match any error codes. This can be replaced with the explicit values that database
returns. In case RET is configured to ACK and DBR entry matches the same, then all the
mapping entries of the current mapping would be skipped and the next SQL mapping,
if configured, would be executed whereas for other return events it would return from
the SQL action.
Global Definitions
Global definitions are placed anywhere in the sqlaccess.config file, but outside
the DBID and SQLAction data structures. They allow you to set up the path to custom
mapping and conversion functions.
The syntax is as follows:
[SQLMapConvLibs [“path_to_lib:path_to_lib:…:path_to_lib”]]
Where:
path_to_lib
Define the list of libraries containing mapping and conversion
functions with full path name.
Advanced SQL Mapping Configuration
This section covers the following advanced SQL Access topics:
• “Developing Custom Functions” (page 369): to extend the functionality of the AAA
Server utilizing the flexible design of the SQL Access feature;
• “Null SQL Statements” (page 370): for SQL statements without mapping or SQL
statements;
• “Time Synchronization” (page 371): to synchronize across multiple AAA Servers;
• “Finite State Table Configuration in the FSM” (page 372): to enable SQL action
execution for complex database interactions or function execution;
• “Stored Procedures” (page 373): to use stored procedures in the database.
Developing Custom Functions
You can define your own mapping and conversion functions, which must reside in
libraries that are located at the paths configured in the SQLMapConvLibs setting of
the global definition in the sqlaccess.config file.Ensure that the names of the
custom functions do not conflict with the names of any other pre-defined or customized
functions.
HP suggests that you use a unique prefix for your custom functions.
Mapping functions use the following prototype:
int32 mappingfunction (void *radrequest, void *data, uint *len)
Where:
Implementing SQL Access 369
