HP-UX AAA Server A.08.01 administrator's guide (T1428-90072, May 2010)

Table 17-17 Lookup AATV Attributes for EAP-SIM
DescriptionAttribute
A fixed-length binary string (octets) attribute that can occur twice or thrice,
and can contain an EAP-SIM authentication vector. The parameter value is a
224-bit binary string (28 bytes). The value constitutes the following:
GSM-Triplet(s)
• RAND = The first 128-bits (16 bytes) of the value.
• Kc = The next 64-bits (8 bytes) of the value.
• SRES = The last 32-bits (4 bytes) of the value.
OR
A fixed-length binary string (octets) attribute that contains the 128-bit value
of the Subscriber Key (Ki) used to authenticate the user.
Subscriber-Key
An optional string attribute that contains the name of the A3 algorithm used
to authenticate the user. This attribute is optional if a default value is
configured for the realm. The value is case-sensitive.
A3-Algorithm
An optional string attribute that contains the name of the A8 algorithm used
to authenticate the user. This attribute is optional if a default value is
configured for the realm. The value is case-sensitive.
A8-Algorithm
AND
Optional Reply item, such as, Session-Timeout and Idle-Timeout.
Other reply attributes
The Lookup AATV for EAP-AKA can also return credentials and other reply items
while retrieving the user's Real-Username. Consequently, the
AUTHREQ_REPLY_QUEUE list of the authreq is updated to contain additional attributes.
Table 17-18 describes the Lookup AATV Attributes for EAP-AKA.
Table 17-18 Lookup AATV Attributes for EAP-AKA
DescriptionAttribute
A fixed-length binary string (octets) attribute that can occur only once, and
contains an EAP-AKA authentication vector. The value is a 576-bit binary
string (72 bytes). The value constitutes the following:
AKA-Vector
• RAND = The first 128-bits (16 bytes) of the value.
• XRES = The next 64-bits (8 bytes) of the value.
• CK = The next 128-bits (8 bytes) of the value.
• IK = The next 128-bits (8 bytes) of the value.
• AUTN = The last 128-bits (8 bytes) of the value.
OR
A fixed-length binary string (octets) attribute that contains the 128-bit value
of the Subscriber Key (Ki) used to authenticate the user.
Subscriber-Key
Pseudonym Identities 267
