HP-UX AAA Server A.08.01 administrator's guide (T1428-90072, May 2010)

Table 17-15 Vendor-Specific Attributes for Pseudonym Database Lookup AATV (continued)
DescriptionAttribute
An integer attribute that contains the number of requested triplets, such
as, RAND, Kc, and SRES. In accordance with RFC4186, the number of
Number-of-Triplets-Requested
triplets required for authentication is two or three. The number of triplets
required for authentication is present to enable the lookup AATV to
generate GSM Triplets, if required.
A string attribute that contains the name of the A3 algorithm to be used
in the GSM Triplet generation. The value is case-sensitive. This attribute
A3-Algorithm
is present only if the realm is configured with a default A3 algorithm. The
attribute is present to enable the lookup AATV to generate GSM Triplets,
if required.
A string attribute that contains the name of the A8 algorithm to be used
in the GSM Triplet generation. The value is case-sensitive. This attribute
A8-Algorithm
is present only if the realm is configured with a default A8 algorithm. The
attribute is present to enable the lookup AATV to generate GSM Triplets,
if required.
Lookup AATV Outputs
The AUTHREQ_REPLY_QUEUE list of the authreq is updated to additionally contain
the following attributes, as described in Table 17-16.
Table 17-16 Lookup AATV Output Attributes
DescriptionAttribute
A string attribute that contains the user's real identity. The identity contains
neither a prefix nor a realm. The identity can be an IMSI constituting up
Real-Username
to 15 decimal digits. If the realm is configured to support non-IMSI real
identities, the identity can be a non-IMSI real username constituting up
to 253 characters.
A Unix epoch date attribute that contains the UTC time at which the
looked up pseudonym expires. This attribute is optional if the lookup
Pseudonym-Expiration-Time
AATV has already checked for an expired Pseudonym-Username. If it
is returned, the HP-UX AAA Server checks whether the
Pseudonym-Username has expired. The lookup AATV may return this
attribute even if the expiration check is performed. If this attribute is
present, the Pseudonym Update AATV is called with the
Last-Used-Pseudonym-Expiration-Time present, along with the
Pseudonym-Expiration-Time value. If this attribute is not returned,
the Last-Used-Pseudonym-Expiration-Time in the database must
be updated by the Lookup AATV.
The Lookup AATV for EAP-SIM can also return credentials and other reply items while
retrieving the user's Real-Username. Consequently, the AUTHREQ_REPLY_QUEUE
list of the authreq is updated to contain additional attributes. Table 17-17 describes
the Lookup AATV Attributes for EAP-SIM.
266 Configuring EAP-SIM and EAP-AKA Authentication Methods
