HP-UX AAA Server A.08.01 administrator's guide (T1428-90072, May 2010)

Table 8-1 Fields in the Local Realm Attributes Form (continued)
FunctionOption
Identifies the authentication method used for the realm:User
Authentication
• Enable EAP: Select this option if user authentication by an EAP challenge
is required. Select one or more EAP types.At least one authentication
method must be selected. For PEAP (EAP-GTC), you must configure the
NULL realm.
The PEAP version ‘0’ only checkbox is displayed if you select
PEAP(EAP-GTC), PEAP(EAP-MSCHAP), or PEAP(EAP-MD5). Select this
checkbox if your supplicant uses the PEAP version 0 protocol.
• Enable RADIUS Standard: Default. Select this option if user authentication
via password checking is required.
If Enable EAP and Enable RADIUS Standard are selected, authentication is
carried out based on the Authentication-Type configuration attribute set in
the RADIUS request.
To indicate the location where the AAA server must retrieve user profiles:User Profile
Storage
• users: Choose this option to store user information locally in AAA Server
flat files. Choosing this option allows you to administer user information
with Server Manager. Server Manager can administer user information
stored locally in the AAA Server flat files only.
• Database Access via SQL or LDAP Server: Choose this option if the user
profile information is stored in an external database. See the individual
chapters for more information.
• OS Security Database: HP-UX operating system HP-UX operating systems
use a number of repositories or “databases” to store information about
hosts, users, passwords, etc. User password lookup is performed through
the name-service switch configured in /etc/nsswitch.conf. See the
nsswitch.conf man page for more information.
• No Store: EAP-TLS Certificates: Choose this option if you are using TLS
and do not want to store user information. If you are using TLS, you are
not required to store user information because the TLS certificates provide
the user information needed for authentication.
• No Store: Allow All Users: Choose this option to allow all requests from a
realm.
• No Store: Deny All Users: Choose this option to deny all requests from a
realm.
Identifies the location, access, and policy parameters for the selected User
Profile Storage.
User Storage
Parameters
Optional. A paranthesized list of one or more aliases, delimited by commas.
Each realm alias is equivalent to the realm name. An alias is provided for user
Alias
convenience or other purposes, such as to save typing when logging on to
your network. Aliases are allowed on wild card entries and are interpreted
as meaning *.alias.
Adding a Realm 107
