statistical information correctly. . These updated values from the meta table are used by the archiving
mechanism to clean up the disk space.
However, calling VACUUM FULL operation is not suggested from the product binaries as it takes exclusive locks on
the tables.Therefore, it is often observed that in a heavily accessed system, the disk size eventually grows as
archiving is not able to fetch the updated data related to pages and rows in the absence of VACUUM FULL
operation.
Configurable parameters of DBConfig.xml
The DBConfig.xml is configuration file for databases used by SysFaultMgmt. This file contains the parameters for
configurations of both LOGDB and evweb DB. These configurations together will decide when the archival activity
should be triggered. The administrator can modify this file but should not modify any of the XML tags. The
administrator should modify only the values of the tags as and when required.
Note: the page size for all databases mentioned here is 8 kB.
Xml Field Names
Max Values
Min Values
Default Values
1.
MaxNumPagesAllowed(LOGDB)
400
10
140
2.
DBRecordLifeTime (LOGDB)
10 1
10
3.
ArchedRecordLifetime (LOGARCHDB)
365
30
365
4.
ArchDBSize (LOGARCHDB)
400
10
340
5.
MaxNumPagesAllowed (evweb DB)
400 10
100
6.
DBRecordLifeTime (evweb DB)
10
1
10
7.
ArchedRecordLifetime (evweb_history)
365
30
365
The in-depth explanation of each of the fields can be found below:
1. MaxNumPagesAllowed (LOGDB) - Argument is NUMBER OF PAGES: It indicates the maximum number of pages
that the current database can hold.
2. DBRecordLifeTime (LOGDB) - Argument is NUMBER OF DAYS: As the max threshold time is 7 days, 10 days
would be sufficient for this parameter. If any of the conditions hit, then the records will
be moved to Archive DB.
3. ArchedRecordLifetime (LOGARCHDB) - Argument is NUMBER OF DAYS: It includes number of days, which is spent
in CURRENT DB also. It will be desirable to have records of one year.
4. ArchDBSize (LOGARCHDB) - Argument is NUMBER OF PAGES: A value of 340 would be sufficient for this
parameter.
Following are the Archival parameters for evweb & evweb_history:
5. MaxNumPagesAllowed (evweb DB) - Argument is NUMBER OF PAGES: It indicates the maximum number of
pages that the current database size can grow before history management can move the events to history
