Diagnostics database archiving guide

Diagnostics database archiving guide
4
SASPROVDB
5553 kB
SASPROVARCHDB
5464 kB
FCPROVDB
5553 kB
FCPROVARCHDB
5464 kB
DISKPROVDB
5553 kB
DISKPROVARCHDB
5464 kB
Total Disk Space
occupied
44068 kB
(IO Providers)
Note: Often the name of the DB i.e., postgres is confused with the postgres DBMS which is software for storing
the data using the relational model. In this document, the convention followed is the term postgres will be used
to specify the name of the s/w and not the DB.
The actual size occupied by these database can be found on the system by listing the size of the data directory
/var/opt/psb/db/pgsql/base ( for IA) or /var/opt/sfmdb/pgsql/base (for PA).
Size of database on a system without IO Providers
du -sk /var/opt/psb/db/pgsql/base
76864 kB
Size of database on a system with IO Providers
du -sk /var/opt/psb/db/pgsql/base
122248 kB
Note: The sizes specified above for the DBs are only the approximate values and should not be considered as
exact values.
The path /var/opt/psb/db/pgsql (IA) or /var/opt/sfmdb/pgsql (PA) are the reference paths for the postgres for its
data directories. It is configured during the installation of the diagnostic products. There is no provision to
changes or re-configure this path during the installation. Any attempt to change this path later or during the
installation can break the product functionality and may lead to unexpected errors in the installation.
Data storage using Database in diagnostic Products
In the typical postgres database, all the data is stored in the data directory. Database internally stores data in the
pages. The typical page size is 8kB.
How the DB size growth is maintained
The SysFaultMgmt uses archiving mechanism to limit the growth of its databases. The archiving mechanism
ensures DB sizes are maintained to configurable limits. Based on archiving policies, data is moved from the
current DB to archive DB. Data from archive DB is further pruned based on the configuration.
The two policies used for transferring data from current DB to archive DB are:
1. Age policy
2. Space policy
Age Policy
The value for this policy can be configured using configuration file DBConfig.xml. For more info on DBConfig.xml
and its parameters, see
Configurable parameters of DBConfig.xml.
