Veritas Volume Manager 5.1 SP1 Release Notes HP-UX 11i v3 (5900-1518, August 2011)

VxVM 5.1 SP1 Licenses
Table 2 (page 8) lists the supported features available with Veritas Volume Manager 5.1 SP1
and the licenses required.
Table 2 License Versus VxVM Feature Availability
Feature Availability by ProductLicense
Concatenation, spanning, rootability and root disk mirroring, multiple disk groups,
striping, mirroring and VEA, coexistence with native volume manager.
Base
Base features plus volume resizing, DRL logging for mirrors, striping plus mirroring,
mirroring plus striping, RAID-5, RAID-5 logging, hot sparing, hot-relocation, online
relayout, Storage Expert, Device Discovery Layer, DMP.
Full
Base and Full features plus Storage Intelligent Storage Provisioning, Dynamic LUN
Expansion, Cross Platform Data Sharing.
HP-UX Serviceguard Storage
Management and Storage
Management for Oracle
NOTE: You must install all the required licenses, otherwise, you will not be able to use certain
features of Veritas Volume Manager 5.1 SP1.
Table 3 Feature Enabled by Full VxVM
Required VxVM License
Veritas Volume Manager 5.1 SP1 for
HP-UX 11i v3Feature
FullSupportedHot-relocation and unrelocation
FullSupportedMirroring (RAID-1)
FullSupportedMaximum number of mirrors supported
FullSupportedOnline migration
FullSupportedOnline relayout
FullSupportedOnline resizing of volumes
FullSupportedPath failover support (active/passive
peripherals)
FullSupportedRAID-5
FullSupportedStriped Mirrors (RAID 1+0)
FullSupportedStriping (RAID 0)
FullSupportedTask monitor
Features Enabled by SG-SMS Products
Table 4 lists the features available with the SG-SMS suite bundles.
Table 4 Features Enabled by HP Serviceguard Storage Management Licenses
T2777EBT2774EBFeature
YesYesVeritas File System
YesYesMulti-Volume File System - Allows more than 1 volume to comprise a file system.
The VxFS intent log and other metadata can be placed on a separate
volume(s), and files can be dynamically striped across multiple volumes,
avoiding volume relayouts when adding storage. This does not license Dynamic
Storage Tiering although both share many underlying technical components.
YesYesVeritas Volume Manager (Full)
YesYesSmartmove (volume resynchronization)
8 Veritas Volume Manager 5.1 SP1 Release Notes
