56 Chapter 3
Getting Started with 3270 Emulation
Fast Path to 3270 Terminal Emulation
Fast Path to 3270 Terminal Emulation
The following fast path provides a brief outline of 3270 display
emulations. It is designed to help experienced users quickly begin
terminal emulation using default settings. For more detailed
instructions, read the rest of this chapter.
Step 1. Prepare for 3270 emulation.
Make sure that you are configured as a TN3270 user. Contact your
System Administrator, or refer to the HP-UX TN3270 Administrators
Guide.
Check that your LANG environment variable is set to the correct
language for the host program. Refer to your operating system
documentation for the names of valid languages.
Step 2. Start the TN3270 emulation program.
Type the following at the HP-UX command prompt:
tn3270[-s[/path/]stylefile] [-e | -b] [-h IDlist] [-l host list]
Motif To start the Motif version of the program, type the following:
xtn3270[-s[/path/]stylefile] [-h IDlist] [-l host list]
End of section
For more information about the command-line options you can use, see
“Starting the TN3270 Emulation Program”.
Step 3. Enable one or more 3270 display sessions.
Before using a session for 3270 emulation, you must initiate
communications with the host (enable the session). When you start the
program, if you see a host screen instead of the main screen of the user
interface, you already have at least one enabled session. If the session
you want to use is already enabled, skip this step and continue with the
next step. If the enabled session is not the session you want, do the
following:
