Chapter 2 49
The TN3270 Emulation Program User Interface
Message Boxes
Message Boxes
The TN3270 emulation program uses message boxes to display messages
as you use the menu interface. Figure 2-10, “Message Box,” shows a
typical message box.
Figure 2-10 Message Box
The TN3270 emulation program provides the following types of message
boxes:
Error
Error messages indicate a condition that requires
action. The condition may be an error detected by the
TN3270 emulation program, for example, the TN3270
emulation program may detect an error in a file you
were attempting to open. It may also be an error that
you made. For example, if you type data that is not
valid in an edit box and choose <OK>, an error message
indicates that you must return to the edit box and
correct the entry or choose <Cancel> to abandon the
dialog.
Warning
Warning messages indicate a condition that may
require action. For example, if you load a style file that
uses color and your terminal does not support color, a
warning message informs you that the color mappings
