338 Appendix F
Printer Filter Application for Double-Byte Character Sets
Model Control Commands
Set a stop position on a line. The tab number can be
any value between the value specified for LM and the
value specified for MPP.
Table F-3, “Default Values for Set Printer Tabs: Horizontal,” shows the
default settings for these parameters. If no value is set in the SPOF then
the default value is used.
Table F-3 Default Values for Set Printer Tabs: Horizontal
Set Printer Tabs: Vertical
The Set Printer Tabs: Vertical command is designed to inform
the filter application of any tab settings concerning vertical movement.
0-1 2 3 4 5 6 7 8 . . N+6
CC 2B count C2 MPL TM BM tab1 tab2 . . tabN
0xCC 0x2B These two bytes identify the MCC Set Printer Tabs
command.
count
The number of total bytes in the MCC Set Printer
Tabs: Vertical command, including the count field
but excluding 0xCC 0x2B.
0xC2
Identifies the Vertical Tab selection.
MPL
Maximum page length (the maximum number of lines
per page). This value cannot exceed 127; otherwise the
default value is used.
TM
Parameter Default Value
MPP 158 (when 6/12 CPI is set)
132 (when 5/10 CPI is set)
LM 1
RM MPP
Horizontal Tab Each Column
